PFX-3152
IMG_1520.jpgPFX-3152
FULL CUTOFF WALL PACK
PFX 3152 Full Cutoff Wallpack Combined with a comprehensive variety of battery backup, controls, and other options to meet your specification or building code and available in two sizes, full cutoff wall pack is designed for perimeter illumination for safety, security and identity. Units have protective polyester finish for long lasting appearance. Ideal for schools, factories, hospitals, warehouses and retail applications.
Resources
Photometry
- PFX3152-MWP0770W27VDDKDAD_5000K_IESNA2002-100-.IES
- PFX3152-MWP07135W27VDDKDAD_5000K_IESNA2002-100-.IES
- PFX3152-MWP07135W27VDDKDAD_4000K_IESNA2002-100-.IES
- PFX3152-MWP07135W27VDDKDAD_3000K_IESNA2002-100-.IES
- PFX3152-MWP0770W27VDDKDAD_4000K_IESNA2002-100-.IES
- PFX3152-MWP0770W27VDDKDAD_3000K_IESNA2002-100-.IES
- PFX3152-MWP07125W27VDDKDAD_5000K_IESNA2002-100-.IES
- PFX3152-MWP07125W27VDDKDAD_4000K_IESNA2002-100-.IES
- PFX3152-MWP07125W27VDDKDAD_3000K_IESNA2002-100-.IES
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
Color / Finish
- Black
- Dark Bronze
- White
Controls Options
- Occupancy Sensor
CRI
- 70
Dimming Range
- 0-100%
- 10%
Lamp Life
- 50000
Lamp Source
- LED
Listings
- UL
- cUL
Lumens
- 4700
- 8200
- 10200
- 18000
- 19400
Mounting
- Wall
Ratings & Compliance
- Wet
Voltage
- 120-277 V
Watts
- 70
- 125
- 135
Weight
- 7.21
- 7.68
- 10
Dimensions
- L: 14.2 In. W: 8.7 In. H: 9.2 In.
- L: 18.1 In. W: 9.5 In. H: 9.7 In.
Dimming Protocol
- 0-10 V
Warranty
- 5 yr
