PFX-3145
Full Cutoff Wall Pack Sensor Ready
Field selectable 3000K, 4000K, and 5000K. Featuring long life LED, universal 120-277 AC voltage, CRI >80 and cast aluminum housing with dark bronze powder coated finish.
Resources
• Operating temperature (ambient): -40°C to 50°C (-40°F to 122°F) .
• Universal 120-277 AC voltage (50-60Hz) is standard.
• 0-10V DC dimming drivers are standard.
• Integrated photocell is standard. Photocell can be enabled or disabled by switch.
• Input transient surge protection = 6kV.
• PF > 0.9; THD < 20%.
• Universal 120-277 AC voltage (50-60Hz) is standard.
• 0-10V DC dimming drivers are standard.
• Integrated photocell is standard. Photocell can be enabled or disabled by switch.
• Input transient surge protection = 6kV.
• PF > 0.9; THD < 20%.
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
Color / Finish
- Bronze
Controls Options
- Photocell
CRI
- 80
Lamp Life
- 51000
- 167000
Listings
- cULus
Lumens
- 5000
- 6000
- 8000
- 9000
- 10000
- 13000
- 15000
- 17000
Materials
- Aluminum
- Die-Cast Aluminum
Mounting
- Wall
Ratings & Compliance
- DLC
- DLC Premium
- IK08
- IP65
Shape
- Rectangular
Voltage
- 100-277 V
Watts
- 30
- 40
- 50
- 60
- 80
- 100
- 120
Weight
- 3.98
- 6
Dimensions
- L: 10 In. W: 8.86 In. H: 6.25 In.
- L: 14.49 In. W: 9.25 In. H: 6.44 In.
Dimming Protocol
- 0-10 V
Warranty
- 5 yr
