PFX-3520

New Product

Bullet Flood Light High Lumen

The PFX-3520 is a high-performance Bullet Flood Light designed to deliver powerful, focused illumination for demanding outdoor environments. Built with a premium powder-coated aluminum housing, this fixture is IP66 rated and cULus listed for wet locations, ensuring durability against the elements. It produces a nominal 9,000 lumens at a 5000K cool white color temperature while consuming only 82W, achieving an impressive efficacy of approximately 111 lm/W. The unit features a standard 1/2" NPT knuckle mount for easy installation and 180° adjustability. For enhanced reliability, it includes 4kV surge protection and a long-life LED system rated for up to 83,000 hours. This professional-grade solution also supports 0-10VDC dimming and is backed by a 5-year warranty.

Specification Sheet

Resources

• Operating temperature (ambient):  -40°C to 40°C (-40°F to 104°F).
• Universal 120-277V AC voltage (50-60Hz) is standard.
• 0-10VDC dimming drivers is standard.
• Input transient surge protection = 4kV.
• Power factor > 0.90.
• Total Harmonic distortion < 20%.

CCT

  • 5000K

Color / Finish

  • Bronze

CRI

  • 70 CRI

Efficacy

  • 110.55 lm/w

Lamp Life

  • 83000 hrs

Lamp Source

  • LED

Listings

  • cULus

Lumens

  • 9096 Lm

Materials

  • Aluminum
  • Glass

Mounting

  • Knuckle
  • Knuckle Wall

Ratings & Compliance

  • FCC
  • IP66
  • Wet

Shape

  • Cone

Voltage

  • 120-277 V

Watts

  • 82.28 w

Weight

  • 5 lbs

Dimensions

  • H: 9.3 In. L: 8.5 In. W: 6 In.

Dimming Protocol

  • 0-10 V

Warranty

  • 5 yr
